Axminster Professional AP170E Dust Extractor

The AP170E is a well-designed mobile dust extractor that comes fitted with a fine dust cartridge...
The AP170E is a well-designed mobile dust extractor that comes fitted with a fine dust cartridge filter as standard. The cartridge filter increases the potential use of this machine to include sanders as well as saws, planers, etc. The extra-large cartridge filter has a rating of 1 micron at 100 % capture rate. Its extra surface area means that the overall airflow is not reduced. The filter cartridge is easy to keep clean with the top mounted crank handle, allowing the filter fins to be wiped manually and thus clean them. A large capacity plastic waste sack captures chippings and shavings, and quick release straps simplify changing the waste sack. A comfortable tubular handle, steel rear wheels and front castor wheels make moving easy. Careful matching of the motor, impeller and housing, results in an efficient machine able to extract chips and dust. The AP170E is a modern, efficient dust extractor that fulfils the requirements of most small professional workshops. The machines are supplied with an adapter (UK system to the Euro system).
Note: This machine requires a 16-amp supply and it's recommended that a C Type breaker is used. If you are unsure about your home electrics, please contact a qualified electrician.

    more
    less
    Further details on the manufacturer

    Axminster

    Axminster

    Axminster has been producing four-jaw chucks for woodturning lathes since 1984. The English company offers a suitable chuck size for every application, not to mention excellent value for money. The chucks along with all accessories are made in England on CNC machines and have been developed over years working closely with experienced turners.

    • Weight 67 kg
    • Motor voltage 230 V / 50 Hz
    • Filter Surface Area 100 % > 1 micron
    • Airflow max. 1200 m³/h with Ø 100 mm / 2250 m³/h with Ø 175 mm
    • Low Air Pressure 3235 Pa
    • Hose Connection Ø 1 x 175 mm or 2 x 100 mm
    • Bin Capacity max. 170 l
    • Dimensions (L x W x H) 1055 mm x 665 mm x 1755 mm
    • Sound power level (LWA) 81 dB(A)
    • Motor power 1500 W
    Article no. 745284
    Brand Axminster
    Freight forwarding goods - Delivery time 3-4 workdays within Germany.

    For delivery worldwide please contact our customer service at +49 (0)9931 4058-902.

    €999.00 per piece(s)

    Prices incl. VAT

    i

    plus shipping costs

    Remember
    Many other models
    Type Price Quantity
    Axminster Professional AP170E Dust Extractor
      €999.00

    Plenty of accessories and spare parts

    Accessories

    Dust Hood, 410 x 325 mm

    Dust Hood, 410 x 325 mm

    Rectangular plastic funnel with spigot to fit 100 mm extraction hoses. For collecting and extracting shavings on e.g. table saws, surface planers and wherever there are no specific extraction connectors.
    €19.90

    incl. VAT plus shipping costs

    Article No. 720549

    Extraction Funnel 250 x 100 mm, Ø 100 mm

    Extraction Funnel 250 x 100 mm, Ø 100 mm

    Funnel-shaped extraction hood with intake size of 250 x 100 mm. Ideal for vacuuming, e.g. on the lathe or for floor cleaning. Depth 270 mm.
    €17.90

    incl. VAT plus shipping costs

    Article No. 727646

    Extraction Trough, 311 x 311 mm

    Extraction Trough, 311 x 311 mm

    Rectangular plastic connection with connection piece for 100 mm suction hoses. The flat trough can be used where there is no space available for conventional funnels. For collecting and extracting chips from e.g. table saws, planing...
    variants
    €16.90

    incl. VAT plus shipping costs

    Article No. 727648

    Extraction Outlet Round, Ø 100 mm

    Extraction Outlet Round, Ø 100 mm

    Connection piece with flange for mounting on machine housings. For 100 mm extraction hoses. Flange diameter 143 mm, bolt circle diameter 128 mm, hole spacing 90 x 90 mm.
    €7.50

    incl. VAT plus shipping costs

    Article No. 727650

    Multiple Stepped Hose Adapter, Ø 25-50 mm

    Multiple Stepped Hose Adapter, Ø 25-50 mm

    More than one adapter can be created depending on the necessary size (separate with a fine-toothed saw).
    variants
    €7.10

    incl. VAT plus shipping costs

    Article No. 727652

    Vacuum Tool Port Adapter, Rigid/Flexible, Ø 100 mm

    Vacuum Tool Port Adapter, Rigid/Flexible, Ø 100 mm

    The flexible part of the connector enables diameter tolerances of extraction pipes to be bridged. Suction hoses with Ø 105 mm (4 inches) are connected to the rigid end. The flexible end can be connected to pipes from Ø 95 mm to Ø 105 mm.
    €16.90

    incl. VAT plus shipping costs

    Article No. 730822

    Hose Connector, Ø 100 mm

    Hose Connector, Ø 100 mm

    Connecting element for two hoses or pipelines or for connecting a hose or pipeline with an extraction nozzle of the same diameter.
    variants
    €10.40

    incl. VAT plus shipping costs

    Article No. 730894

    Hose Reduction, Ø 100/63 mm

    Hose Reduction, Ø 100/63 mm

    Connecting element for two hose or pipelines of different diameters, or for connecting a hose or pipeline with suction nozzles of different diameters.
    variants
    €6.90

    incl. VAT plus shipping costs

    Article No. 730898

    Chip Bags, 800 x 1000 x 0.1 mm, 5 Pieces

    Chip Bags, 800 x 1000 x 0.1 mm, 5 Pieces

    Transparent polyethylene bags suitable for extraction systems.
    variants
    €19.90

    incl. VAT plus shipping costs

    Article No. 725057
